AS spacer
Used to compensate for wall and roof tolerances
EJOT® ejotherm® SDK U 8
Specification
-
Applications
- Fastening of rail-systems
- Screw-in anchor for rails
- For fixing holding and base rails
- Approved for all categories of building materials
-
Properties
- Approved for all categories of building materials
- Shortest embedment depths, minimum drill hole depths
- Highest loads for maximum safety
- Economic anchor usage
- Premounted screw for quick installation
- To compensate facade tolerances use spacers EJOT AS
-
Technical specifications
- Anchor diameter: 8 mm
- Collar diameter:16 mm
- Drill hole depth h1 >: 35 mm (75 mm)
- Embedment depth hef >: 25 mm (65 mm)
- Screw drive: TX30
- Use categories acc. to ETA: A, B, C, D, E
- German DIBt approval: Z-21.2-1769
- European Technical Approval: ETA-04/0023
Values in parentheses: anchoring in aerated concrete (use category E)
Additional information
ETICS products are only available from system suppliers. Please email salesuk@ejot.com or call 01977 687040 for further information.
Filter
Selected filters
| Orderidentifier | Article Number | Anchor diameter mm | Length mm | Substrate Categories | Unit | |||
|---|---|---|---|---|---|---|---|---|
| Ejotherm SDK U 8 x 45 | 8798045400 | 8.0 | 45.0 | A-E | Anchors for Rail Systems | screw-in-anchor | 20.0 | 100 |
Specifications
|
||||||||
| Ejotherm SDK U 8 x 65 | 8798065400 | 8.0 | 65.0 | A-E | Anchors for Rail Systems | screw-in-anchor | 40.0 | 100 |
Specifications
|
||||||||
| Ejotherm SDK U 8 x 85 | 8798085400 | 8.0 | 85.0 | A-E | Anchors for Rail Systems | screw-in-anchor | 60.0 | 100 |
Specifications
|
||||||||
| ejotherm SDK U 8 x 105 | 8798105400 | 8.0 | 105.0 | A-E | Anchors for Rail Systems | screw-in-anchor | 80.0 | 100 |
Specifications
|
